2023 E-Z-GO Express L6 Gas
Roll over image to zoom in
$16,129.00
| Engine | |
|---|---|
| Engine Type | 4 Cycle 24.5 cu in (401 cc) |
| Displacement | 401 cc |
| Horsepower | 13.5 HP (10.1 kW) |
| Fuel Capacity | 5.96 gal. (22.6 L) Tank |
| Chassis | |
|---|---|
| Front Suspension | Leaf Springs with Hydraulic Shock Absorbers |
| Rear Suspension | Leaf Springs with Hydraulic Shock Absorbers |
| Front Tires | MT Paramount, 23×10-14, Radial, SPDR Alloy Wheel |
| Rear Tires | MT Paramount, 23×10-14, Radial, SPDR Alloy Wheel |
| Brakes | Rear Wheel Mechanical Self-Adjusting Drum |
| Frame Type | Welded Steel with Powder-Coat Protection |
| Dimensions | |
|---|---|
| Curb Weight | 1190 lb. (540 kg) |
| Wheelbase | 97 in. (245 cm) |
| Length | 144 in. (364 cm) |
| Width | 49 in. (125 cm) |
| Height | 83 in. (211 cm) |
| Transmission | |
|---|---|
| Transmission | CVT |
| Drive Train | Continuously Variable Transmission (CVT) |
| Top Speed | 19 mph (31 kph) |
| General | |
|---|---|
| Passenger Capacity | 6 |
| Weight Capacity | 1200 lb. (544 kg) |
| Colors | Black, Electric Blue, Flame Red, Inferno Red, Metallic Charcoal, Ocean Gray, Platinum, Bright White, Slate |
Elevate your Expectations
Explore more than ever before with the all-new E-Z-GO Express™ L6. The elevated experience of the Express L6 continues with the improved front suspension on ELiTE vehicles, for enhanced drivability and maneuverability. With a choice of an efficient 13.5-HP closed-loop EFI gas powertrain, or our 4.2 twin, or 6.2 triple maintenance-free ELiTE lithium battery packs, the Express L6 golf cart will heighten every adventure. With more range and improved drivability, this 6-passenger golf cart exceeds every expectation
Dimensions
- Overall Length: 144 in (364 Cm)
- Overall Width: 49 in (125 Cm)
- Overall Height (W/O Roof): 55.5 in (141 Cm)
- Overall Height (W/ Roof): 83 in (211 Cm)
- Wheel Base: 97 in (245 Cm)
- Front Wheel Track: 38.5 in (98 Cm)
- Rear Wheel Track: 38.5 in (98 Cm)
- Ground Clearance @ Differential: 7.0 in (18 Cm)
Power
- Valve Train: Single Cylinder Ohv
- Motor Type: 4 Cycle 24.5 Cu In. (401 Cc)
- Fuel System: Closed-Loop Electronic Fuel Injection
- Horsepower (Kw): 13.5 Hp (10.1 Kw) Exceeds Sae J1940 Std
- Electrical System: Starter/Generator – Solid State Regulator
- Batteries (Qt.Y/Type): One, 12 Volt Maintenance Free
- Key or Pedal Start: Pedal
- Air Cleaner: Replaceable Dry Cartridge
- Lubrication: Pressurized Oil System
- Oil Filter: Spin-On
- Cooling System: Air Cooled
- Fuel Capacity: 5.96 Gal. (22.6 L) Tank
- Drivetrain: Continuously Variable Transmission (Cvt)
- Transaxle: Differential With Helical Gears
- Gear Selection: Forward-Reverse
- Rear Axle Ratio: 11.47:1 (Forward); 14.35:1 (Reverse)
Performance
- Seating Capacity: 6-Passenger
- Dry Weight: 1150 Lb (522 Kg) (Wihtout Battery)
- Curb Weight: 1190 Lb (540 Kg)
- Vehicle Load Capacity: 1200 Lb (544 Kg)
- Turnig Radius: 14.4 Ft (4.4 M)
- Outside Clearance Circle: 28.8 Ft (8.8 M)
- Speed (Level Ground): 19 Mph (31 Kph)
Steering & Suspension
- Steering: Self-Compensating Rack and Pinion
- Suspension: Leaf Springs With Hydraulic Shock Absorbers
- Service Brake: Rear Wheel Mechanical Self-Adjusting Drum
- Parking Brake: Self-Compensating, Single Point Engagement
- Tires: Mt Paramount, 23×10-14, Radial, Spdr Alloy Wheel
Body & Chasis
- Frame: Welded Steel With Powder-Coat Protection
- Body & Finish: Injection Molded Tpo
- Available Body Colors: Black, Electric Blue, Flame Red, Inferno Red, Metallic Charcoal, Ocean Gray, Platinum, Bright White, Slate
- Available Seat Colors: Black, Grey on Black, White on Beige
- Available Premium Seat Colors: Black, Mushroom, Grey
highlights
- Functional Dashboard With Storage: Premium Golf Cart Dashboard With Versatile Cup and Technology Holders and More Dash Storage and Style.
- New Rear Facing Seat With Enclosed Storage: Rear-Facing Golf Cart Seat Enabling a 6 Passenger Ride Featuring Convenient Enclosed Storage for All of Your Adventures.
- Lifted Suspension: Elevate Your Golf Cart With the Standard Lifted Suspension.
- New Tire and Wheel Options: Premium Tires and Wheels Improve Ride Quality and Give Another Level of Customization to Your 6 Passenger Golf Cart.
Key features
- Spacious legroom and front room operator area
- Smooth and quiet Paramount M/T Tires with Radial SPDR Wheel
- New Rear Facing Seat with Cup-holders
- Functional dash with versatile cup and technology holders and three storage areas
- Dashboard Storage Pockets
- Premium Steering Wheel
- Large Fender Flares
- Dual USB Ports
- Multi-Function Speed, State Of Charge and Hour Meter Gauge (Electric Only)
- DC/DC Converter (Electric Only)
- 72-Volt AC Powertrain (Electric Only)
- Fuel Gauge (Gas Only)
- Low Oil Indicator (Gas Only)
